Metal mask laser-cut stencils are essential tools in PCB assembly, used to accurately apply solder paste onto circuit boards. Made from high-quality materials like SUS 304, Fine Grain, or Nickel, these stencils are precisely cut using laser technology to ensure clean, consistent aperture shapes.

They are preferred in the industry for their high precision, durability, and reliable paste release—making them ideal for fine-pitch components and high-volume production. Custom designs are also available to meet specific manufacturing needs.

Laser Cut Stencil

  • Our available materials include:

    • SUS 304 – Standard stainless steel, offering excellent strength and corrosion resistance

    • Fine Grain (FG) – Enhanced material for superior aperture definition and paste release

    • Nickel – Suitable for high-precision applications requiring excellent wear resistance and smooth aperture walls

    We offer stencil thicknesses ranging from 0.02 mm to 0.5 mm, allowing for flexibility based on specific solder paste, component, and board requirements.

    If you are unsure which material or thickness is best suited for your process, please contact us. Our team will be glad to assist you in selecting the most appropriate configuration for your production environment.

  • We offer a range of standard frame sizes to suit various production needs. Our most commonly requested frame sizes include:

    • 650 mm × 650 mm

    • 29 inch × 29 inch

    These dimensions are widely used across SMT manufacturing lines and are compatible with most standard stencil printers and equipment.

    If you require custom frame sizes or have specific mounting requirements, please contact us — we are happy to accommodate your production needs.

  • For non standard design, non-standard apertures, step stencils, selective thickness areas, or designs for uncommon board layouts, our team is equipped with the expertise and technology to deliver precise, high-performance results. Every custom stencil is manufactured with the same attention to detail and quality that defines our standard products.

    If you have a specialized design in mind or need technical support developing a custom solution, please reach out to us. We are committed to working closely with you to meet your exact specifications. text goes here

Single and multiple step stencils are specialized stencils designed with varying thickness levels to control the volume of solder paste applied to different areas of a PCB. This technique is essential when working with mixed component heights, fine-pitch ICs, or larger thermal pads on the same board.

Step stencils are precisely laser cut and chemically etched to ensure smooth transitions between thicknesses, allowing for accurate solder paste deposition without compromising stencil integrity.

These stencils are ideal for complex assemblies that require targeted paste volume control for optimal soldering performance. We offer fully customized step stencil solutions—whether you need a single step-down or multiple stepped regions—to support your specific assembly requirements.

Single/Multi Step Stencil

  • Our available materials include:

    • SUS 304 – Standard stainless steel, offering excellent strength and corrosion resistance

    • Fine Grain (FG) – Enhanced material for superior aperture definition and paste release

    • Nickel – Suitable for high-precision applications requiring excellent wear resistance and smooth aperture walls

    We offer stencil thicknesses ranging from 0.02 mm to 0.5 mm, allowing for flexibility based on specific solder paste, component, and board requirements.

    If you are unsure which material or thickness is best suited for your process, please contact us. Our team will be glad to assist you in selecting the most appropriate configuration for your production environment.

  • We offer a range of standard frame sizes to suit various production needs. Our most commonly requested frame sizes include:

    • 650 mm × 650 mm

    • 29 inch × 29 inch

    These dimensions are widely used across SMT manufacturing lines and are compatible with most standard stencil printers and equipment.

    If you require custom frame sizes or have specific mounting requirements, please contact us — we are happy to accommodate your production needs.

  • For non standard design, non-standard apertures, step stencils, selective thickness areas, or designs for uncommon board layouts, our team is equipped with the expertise and technology to deliver precise, high-performance results. Every custom stencil is manufactured with the same attention to detail and quality that defines our standard products.

    If you have a specialized design in mind or need technical support developing a custom solution, please reach out to us. We are committed to working closely with you to meet your exact specifications. text goes here

Electroform stencils are high-precision stencils manufactured through an electroforming process, which deposits nickel layer by layer to form the stencil. This method results in exceptionally smooth aperture walls, making electroform stencils ideal for applications requiring ultra-fine pitch, micro components, or high-accuracy paste release.

Due to their excellent paste release characteristics and superior dimensional stability, electroform stencils are often used in high-density SMT assemblies, 01005 components, and applications with complex or delicate layouts.

We offer electroform stencils tailored to your specifications, providing enhanced performance for critical, high-reliability PCB assemblies.

Electroform Stencil

Wiper Roll

Wiper rolls are used in SMT printers to clean the underside of the stencil between print cycles. They help remove excess solder paste and prevent defects such as bridging or smearing, ensuring clean, accurate prints and reliable solder joints.

  • We offer high-performance wiper rolls in the following materials:

    • C1 – Standard material suitable for general-purpose cleaning

    • C100 – Enhanced durability and absorption for more demanding environments

    • Hyperclean – Premium material offering superior cleanliness, low lint, and optimal solvent compatibility for high-precision applications

  • Our wiper rolls are compatible with major SMT printer brands and are available in various widths and lengths to suit your production setup. If you're unsure which type suits your process best, feel free to contact us — we’ll be happy to assist.

    If you have a specialized design in mind or need technical support developing a custom solution, please reach out to us. We are committed to working closely with you to meet your exact specifications. text goes here
